Cement Mortar Precast Counter Current Mixer Planetary Site Construction

Name: Cement Mortar Precast Counter Current Mixer Planetary Site Construction
Brand: PERMIX
Price: 1 USD

Brand Name : PERMIX

Model Number : PMC1000

Certification : CE

Place of Origin : JIAOZHOU CHINA

MOQ : 1 unit

Price : Negotiation

Supply Ability : 10-20 units per month

Delivery Time : 15-20days

Packaging Details : Export Standard Package

Color : Orange

Material : Steel

Input weight : 2400kgs

Mixing Power : 37kw

Blade QTY : 2*2

Input capacity : 1500L

Contact Now

Counter Current Mixer Planetary Site Construction Cement Mortar Precast PMC1000

Features of Planetary mixer

Planetary mixer is a new type of high efficiency, stirring without dead corner equipment; it has a unique form of stirring. Planet drive the two stirring shaft turns around the material barrel, at the same time, the stirring shaft is high-speed operation, so that the material is strong shearing action, achieve full dispersion and mixing effect. In addition to the equipment within the knife scraping wall around the cylinder axis rotation, will be stuck on the wall material scraping and then put them into mixing shear, that make no residual material in the mixer and mixing effect is more ideal. Cylinder with special seal structure and have the pressure or vacuum stirring. Mixer has good deaeration effect, the cylinder body can be designed to be heated or cooled according to customers' needs. The cover is hydraulic lifting, convenient to operate and clean and the cylinder body can move freely.

Cement Mortar Precast Counter Current Mixer Planetary Site Construction

Technical Data
	PMC50	PMC 100	PMC 150	PMC 250	PMC 330	PMC 500	PMC 750	PMC 1000	PMC 1500	PMC 2000	PMC 2500	PMC 3000	PMC 4000	PMC 4500
Output capacity(L)	50	100	150	250	330	500	750	1000	1500	2000	2500	3000	4000	4500
Input capacity(L)	75		225	375	500	750	1125	1500	2250	3000	3750	4500	6000	6750
Input capacity(kg)	120		360	600	800	1200	1800	2400	3600	4800	6000	7200	9600	10800
Diameter of Mixing Tank(mm)				1300	1540	1900	2192	2496	2796	3100	3400	3400
Mixing Power kw	3	7.5	11	15	18.5	22	30	37	55	75	90	110	160	200
Blade QTY	1/2	1*2	1*2	1*2	1*2	1*2	1*3	2*2	2*2	3*2	3/6	3/9	3/9	3/9
Side Scraper QTY	1	1	1	1	1	1	1	1	1	1	1	1	1	1
Bottom Scraper QTY	1	1	1	1	1	1	1	1	1	1	2	2	2	2
Weight(kg)	700		1000	1200	1700	2000	3500	6000	7000	8500	10500	11000	16000	18000
